Off-Road Hills & Heavy Loads / 85 Nm Torque

Up to 73 km Range

Shimano STePS EP801 Motor

Alloy Frame/ RockShox Fork

160mm Front Travel / 160mm Rear

630Wh Battery

Have a Question? Ask an expert on 1800 990 523

Product Details

Description

The Merida eOne-Sixty 400 Electric Enduro Bike in Gunmetal Grey/Black is built for trail enthusiasts. It features a sturdy aluminum frame, 160mm of suspension travel, and a powerful Shimano EP801 motor with a 630Wh battery, making it ideal for conquering tough terrains.

Key Features

Durable eONESIXTY LITE IV MAT frame
160mm rear suspension travel
Rock Shock Psylo Silver R fork
Shimano Cues U4000 drivetrain
Integrated Shimano EP801 motor

Specifications

Product Overview

Product

Merida eOne-Sixty 400 Electric Enduro Bike 630Wh Battery Gunmetal Grey/Black

Brand

Merida

Parent SKU

Merida25eONESIXTY400GunmetalGreyBlack

SKU

Merida25eONESIXTY400GunmetalGreyBlack

Size SKUs

SM: MEEB2502814
MD: MEEB2502815
LG: MEEB2502816
XL: MEEB2502817

Matrix Barcodes

SM: 25028142814
MD: 25028152815
LG: 25028162816
XL: 25028172817

Year Model

2025

Product Features

Frame Material

Alloy

Frame Style

Crossbar

Colour

Grey

Wheel Size

29"

Brake Type

Hydraulic Disc Brake

Gears

1 x 9

Front Travel

160mm

Rear Travel

160mm

Motor and Battery System

Drive Type

Mid Drive

Motor Brand

Shimano

Motor

Shimano EP801; 85Nm 25KPH

Torque (Nm)

Motor Climbing Ability

Off-Road Hills & Heavy Loads

Battery Size (Watt-Hours)

630

Battery

Shimano EN806; 630Wh

Max. Range (KMs)

Display

Shimano SC-EN500

Declared Article Number (NSW)

ULL-104179-EA

Build

Frame

eONESIXTY LITE IV MAT aluminium 160 STR 29x26 max WHS 148x12 AST intube 750 Wh

Fork

Rock Shock Psylo Silver R; 160 STR; Tapered; 44mm fork offset; 29x2.6" max WHS

Shock

Rock Shock Deluxe

Handlebars

MERIDA EXPERT eTR; 780 WHB; XS,S 20RHB ; M,L,XL 30RHB

Headset

Acros ICR MERIDA EXTERNAL neck w/ Blocklock

Grips

MERIDA EXPERT EC

Stem

MERIDA EXPERT eTR II; MAT aluminium; 35 DSH; 0 ASD; Supernova mount

Bottom Bracket

included

Pedals

VP VPE-533

Saddle

MERIDA COMP SL; V-mount; incl. MERIDA minitool

Seat Post

MERIDA EXPERT TR II; 34.9 DSP; 0 SSB; XS: 125 SPT - S: 150 SPT - M/L/XL: 200 SPT - XL: 230 SPT

Seat Clamp

MERIDA EXPERT

Wheels

Wheel Size

29"

Rims

MERIDA EXPERT TR II; 110x15 WHF; 148x12 WHR; 28 IWR; MAT aluminium; Tubeless ready (tubeless tape and valves not included); front 29"; rear 27.5"

Tyres

F: Maxxis Assegai; 29x2.5 "; fold; TR EXO+ 3C MaxxGrip | R: Maxxis Minion DHR II; 27.5x2.4 "; fold; 3C DD TR MaxxTerra

Groupset

Crankset

Shimano FC-EM600; 165 mm for all sizes

Chain

Shimano LG500

Front Rotor

Tektro TR203-45; 203mm

Rear Rotor

Tektro TR203-45; 203mm

Rear Derailleur

Shimano Cues U4000; GS

Cassette

9 Speed

Frequently Asked Questions

What is the Merida eOne-Sixty 400 used for?

The Merida eOne-Sixty 400 is a high-performance electric enduro bike designed to handle challenging trails and descents with confidence.

Why choose the Merida eOne-Sixty 400?

Ideal for enduro enthusiasts, the Merida eOne-Sixty 400 combines durable construction, reliable Shimano components, and advanced suspension to excel in demanding off-road conditions.

Who is the Merida eOne-Sixty 400 designed for?

This bike is crafted for enduro riders looking to push their limits on technical trails and descents, relying on quality components for performance and reliability.

Disclaimer

Please Note: Before using this vehicle, check the applicable local laws relating to your intended use of the vehicle on roads and road related areas. Please ride responsibly and follow your local laws. We do not recommend modifying your electric bike or electric scooter.

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Merida eOne-Sixty 400 Electric Enduro Bike 630Wh Battery Gunmetal Grey/Black we suggest the following size.

More playful More stable

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Range

Calculate your range

E-Bike Range Estimator

Free Test Rides

Come into your local store to test ride an E-Bike today

Find a store

Shop Our E-bikes

Shop our collection of electric bikes

Shop Now

SHIMANO CUES U4000 DRIVETRAIN

The Shimano Cues U4000 drivetrain ensures smooth and reliable shifting, making it perfect for navigating tough enduro trails. Its performance is tailored for those who demand precision in their rides.

ROCK SHOCK PSYLO SILVER R FORK

Equipped with 160mm of travel, the Rock Shock Psylo Silver R fork enhances control and responsiveness on rugged terrain. This feature is essential for aggressive riding, allowing for better handling on descents.

TEKTRO TR203-45 HYDRAULIC DISC BRAKES

The Tektro TR203-45 hydraulic disc brakes provide exceptional stopping power with 203mm rotors. This ensures safety and reliability, especially during steep descents and adverse weather conditions.

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

Your selected size: -

Legend

Available size

Current size

Unavailable size

Suggested sizing

Merida eOne-Sixty 400 Electric Enduro Bike 630Wh Battery Gunmetal Grey/Black geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

29"

Stack

624

628

633

637

642

Reach

419

439

459

479

499

Top Tube Length

546

567

589

610

632

Seat Tube Length

400

410

425

445

465

Seat Tube Angle

78.5

78.4

78.3

Fork Length

581

Head Tube Length

100

105

110

115

120

Head Tube Angle

64.4

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

763

757

751

749

744

Minimum Seat Height

Maximum Seat Height
