Norco XFR 3 Hybrid Bike Green/Black

Brand: Norco

SKU: Select a size

Size: Select a size

SM MD LG XL

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Express Shipping $19.00

Select a size to view stock availability at this location.

Alloy Frame/ Suntour Fork

under 100mm Front Travel

700c Wheel Size

Mechanical Disc Brake

Shimano Tourney Groupset

3 x 7 Speed

Have a Question? Ask an expert on 1800 990 523

Product Details

Description

The Norco XFR 3 Hybrid Bike is designed for daily commutes and exercise, offering comfort on various surfaces. It features a Suntour XCE28 Suspension Fork with 80mm travel to absorb bumps and fast-rolling multi-terrain tires for a smooth ride. The upright geometry and X6 aluminum frame provide stability while remaining lightweight and easy to control.

Specifications

Product Overview

Product

Norco XFR 3 Hybrid Bike Green/Black

Brand

Norco

Parent SKU

21NorcoFR3GreenBlack

Size SKUs

SM: NOHB2100321824
MD: NOHB2100321825
LG: NOHB2100321826
XL: NOHB2100321827

Year Model

2021

Product Features

Frame Material

Alloy

Frame Style

Crossbar

Colour

Green

Wheel Size

700c

Brake Type

Mechanical Disc Brake

Gears

3 x 7

Front Travel

under 100mm

Weight Limit

150kg (includes bike)

Build

Frame

Alloy

Fork

SR Suntour XCE28, 80mm

Handlebars

Aluminum, 660mm (XS), 680mm (S, M) 700mm (L, XL), 25mm Rise

Grips

Norco

Stem

Aluminum, 60mm Reach, 31.8mm Clamp

Bottom Bracket

Cartridge Bearing, BSA Threaded

Pedals

City, Black

Saddle

Norco Sport

Seat Post

Aluminum, 27.2mm

Wheels

Wheel Size

700c

Rims

WTB SX19 Double Wall, 32H, 29"

Hubs

Alloy, Weather Sealed, 9x100mm, 6-bolt

Tyres

Kenda 700x50c Fast Rolling

Spokes

Black Stainless

Groupset

Crankset

Prowheel Alloy, 48/38/28T, 170mm (XS, S, M), 175mm (L, XL)

Chain

KMC Z7

Brakes

Mechanical Disc

Front Rotor

160mm

Rear Rotor

160mm

Shifters

Shimano ST-EF500 EZ-Fire

Front Derailleur

Shimano Tourney FD-TY710

Rear Derailleur

Shimano RD-TX800

Cassette

7 Speed

Disclaimer

Please Note: Before using this vehicle, check the applicable local laws relating to your intended use of the vehicle on roads and road related areas. Please ride responsibly and follow your local laws. We do not recommend modifying your electric bike or electric scooter.

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Norco XFR 3 Hybrid Bike Green/Black we suggest the following size.

More comfort More speed

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Riders Height (cm)

Norco XFR 3 Hybrid Bike Green/Black geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

700c

Stack

634

648

662

676

Reach

380

405

430

455

Top Tube Length

562

591

620

649

Seat Tube Length

430

470

510

550

Seat Tube Angle

74.0

Fork Length

Head Tube Length

125

140

155

170

Head Tube Angle

69.0

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

650

668

704

736

Minimum Seat Height

Maximum Seat Height
