Merida eOne Sixty 10K Electric Mountain Bike Glossy Sparkling Blue/Matt Black

Merida eOne Sixty 10K Electric Mountain Bike Glossy Sparkling Blue/Matt Black

Brand: Merida

SKU: MEEB2169317

Size: LG

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Express delivery — fastest option $19.00

Select a size to view stock availability at this location.

Steep Hills & Heavy Loads / 85 Nm Torque

Up to 59 km Range

Shimano STePS EP8 Motor

Carbon Frame/ Fox Fork

160mm Front Travel

504Wh Battery

Have a Question? Ask an expert on 1800 990 523

Product Details

Description

The Merida eOne Sixty 10K is a premium electric mountain bike crafted for dedicated trail enthusiasts. With its lightweight carbon-alloy frame, powerful Shimano EP8 motor, and robust 630Wh battery, this bike excels in performance and handling on rugged terrains. Advanced suspension components and high-quality brakes ensure a smooth, controlled ride, making it perfect for both challenging climbs and thrilling descents.

Key Features

Shimano EP8 Drive Unit with 85Nm
Shimano E8036 Battery with 630Wh capacity
Carbon/Alloy Frame with 150mm travel
FOX 38 Factory eMTB+ Fork with 160mm travel
Shimano XTR Hydraulic Disc Brakes with 4 pistons

Specifications

Product Overview

Product

Merida eOne Sixty 10K Electric Mountain Bike Glossy Sparkling Blue/Matt Black

Brand

Merida

Parent SKU

21MeridaeOneSixty10KGlossySparklingBlueMattBlk

Size SKUs

MD: MEEB2169306
LG: MEEB2169317
XL: MEEB2169328

Year Model

2021

Product Features

Frame Material

Carbon

Colour

Blue

Wheel Size

29" / 27.5" (Varies by Frame Size)

Brake Type

Hydraulic Disc Brake

Gears

1 x 12

Front Travel

160mm

Charge Time

Weight Limit

140kg (includes bike)

Motor and Battery System

Drive Type

Mid Drive

Motor Brand

Shimano

Motor

Shimano EP8; 85Nm 25KPH

Torque (Nm)

Motor Climbing Ability

Steep Hills & Heavy Loads

Battery Size (Watt-Hours)

504

Battery

Shimano E8036; 630Wh

Max. Range (KMs)

Charge Time (Hours)

Display

Shimano STePS

Build

Frame

eONE-FS CFA II; MAT carbon; 150 STR; 29/27.5" WHS; 148x12 AST; intube;

Fork

FOX 38 Factory eMTB+; Air; 160 STR; Tapered; 51mm fork offset

Handlebars

MERIDA Expert eTR; 780 Wide; 20 Rise

Grips

MERIDA Expert EC

Stem

MERIDA EXPERT eTRII; MAT aluminium; 35 DSH; 0 ASD

Pedals

VP; VPE-527

Saddle

MERIDA Expert CC; V-mount

Seat Post

SP REVERB AXS; 30.9 DSP; 0 SSB; XS 125 SPT - S/M 150 SPT - L/XL 170 SPT

Wheels

Wheel Size

29" / 27.5" (Varies by Frame Size)

Rims

DT Swiss Spline HXC1250 spline 30 boost; 110x15 WHF; 148x12 WHR; 30 IWR; Centerlock; microspline; MAT carbon; Tubeless ready (tubeless tape and valves included)

Hubs

DT Swiss

Tyres

F: Maxxis Assegai; 29x2.5 "; fold; 3C MaxxGrip DD , R: MINION DHR II DD; 27.5x2.6 "; wire bead; 3C DD

Spokes

DT hybrid 2

Groupset

Crankset

Shimano FCEM900; 165 mm all sizes; hollow

Chain

CNM9100

Brakes

Shimano XTR; 4 piston

Shifters

Shimano XTR M9100

Rear Derailleur

Shimano XTR Shadow+

Cassette

12 Speed

Frequently Asked Questions

What is the Merida eOne Sixty 10K Mountain Bike used for?

The Merida eOne Sixty 10K is designed for tackling challenging mountain trails and providing an exhilarating riding experience. Its powerful motor and advanced suspension make it ideal for both climbing and descending rugged terrains.

Why choose the Merida eOne Sixty 10K Mountain Bike?

Choosing the Merida eOne Sixty 10K means opting for a high-performance electric mountain bike that combines cutting-edge technology with premium components. Its lightweight frame, powerful motor, and superior suspension ensure an unmatched riding experience.

Who is the Merida eOne Sixty 10K Mountain Bike designed for?

The Merida eOne Sixty 10K is designed for serious mountain bikers who seek performance and reliability on challenging trails. It caters to riders looking for a high-quality e-MTB that can handle both steep climbs and technical descents with ease.

Disclaimer

Please Note: Before using this vehicle, check the applicable local laws relating to your intended use of the vehicle on roads and road related areas. Please ride responsibly and follow your local laws. We do not recommend modifying your electric bike or electric scooter.

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Merida eOne Sixty 10K Electric Mountain Bike Glossy Sparkling Blue/Matt Black we suggest the following size.

More playful More stable

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Range

Calculate your range

E-Bike Range Estimator

Free Test Rides

Come into your local store to test ride an E-Bike today

Find a store

Shop Our E-bikes

Shop our collection of electric bikes

Shop Now

Advanced Motor Technology

The Merida eOne Sixty 10K features the Shimano EP8 motor, delivering 85Nm of torque for powerful assistance. This efficient motor enhances your riding experience, especially on steep trails.

Superior Suspension System

Equipped with a FOX 38 Factory eMTB+ fork offering 160mm of travel, this bike absorbs shocks and bumps effectively. The combination of front and rear suspension provides a smooth ride over rough terrain, ensuring greater control and comfort.

Premium Components

The bike boasts Shimano XTR hydraulic disc brakes, offering exceptional stopping power and reliability. With high-end wheels and tires, the eOne Sixty 10K is built for performance and durability on any trail.
