Merida Dirt 500 Dirt Jumper Bike Black

Brand: Merida

SKU: Select a size

Other Colours

Grey

Black

Size: Select a size

MD LG

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

$1,399.00 Full price

$1,399.00

Club price

$1,599.00 Full price

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Express Shipping $19.00

Select a size to view stock availability at this location.

Alloy Frame/ Manitou Fork

100mm Front Travel

26" Wheel Size

Hydraulic Disc Brake

1 x 1 Speed

Have a Question? Ask an expert on 1800 990 523

Product Details

Description

The Merida Dirt 500 Dirt Jumper Bike is designed for those who crave the thrill of dirt jumping, pump tracks, and trail riding. Built with a robust alloy frame and equipped with a Manitou Circus Expert fork, this bike offers excellent shock absorption and control. Its hydraulic disc brakes ensure reliable stopping power, while the single-speed drivetrain provides simplicity and ease of maintenance. With tubeless-ready rims and Kenda K-Rad tires, the Merida Dirt 500 is ready to tackle any terrain with confidence.

Key Features

Alloy frame for durability
Manitou Circus Expert fork
Hydraulic disc brakes
Single-speed drivetrain
Tubeless-ready rims

Specifications

Product Overview

Product

Merida Dirt 500 Dirt Jumper Bike Black

Brand

Merida

Parent SKU

MERE26DIRT500BLACK

SKU

MERE26DIRT500BLACK

Size SKUs

MD: MERE2602940
LG: MERE2602941

Year Model

2026

Product Features

Frame Material

Alloy

Frame Style

Crossbar

Colour

Black

Wheel Size

26"

Brake Type

Hydraulic Disc Brake

Gears

1 x 1

Front Travel

100mm

Build

Frame

DIRT TFS; MAT aluminum; 26 WHS; 135x10 AST; BSA BBR

Fork

Manitou Circus Expert, Air; 100 STR; 110x20mm; 41mm fork offset; tapered

Handlebars

MERIDA COMP TR; MAT aluminium; 780 WHB; 20 RHB

Headset

FSA NO.57SC

Grips

MERIDA COMP DR

Stem

MERIDA COMP TR; MAT aluminium; 35 DSH; 0 ASD; 40mm

Bottom Bracket

Samox BSA 24mm EB2401

Pedals

VP VPE-536

Saddle

MERIDA COMP DR

Seat Post

MERIDA COMP DR; MAT aluminium; 27.2 DSP; 0 SSB; 250mm length

Seat Clamp

MERIDA EXPERT

Accessories

Rear brake adapter SM-MA-R160P/S

Wheels

Wheel Size

26"

Rims

Alexrims MD30; 30 IWR; MAT aluminum; 32H; tubeless ready

Hubs

F: Novatec DH61SB-HL; 110x20 WHF; 32 SPH; 6 bolt | R: Novatec D256SBT; 135x10 M10 WHR; 32 SPH; 6 bolt; 14t

Tyres

F: Kenda K-Rad K905 ; 26x2.3"; wire | R: Kenda K-Rad K905 ; 26x2.3"; wire

Spokes

Black stainless

Groupset

Crankset

MERIDA Expert TR II; 32 ATC; 160mm

Chain

KMC Z1 narrow

Brakes

F: Shimano MT200; 2 piston | R: Shimano MT200; 2 piston

Front Rotor

Shimano RT10; 180mm

Rear Rotor

Shimano RT26; 160mm

Cassette

Single Speed

Frequently Asked Questions

What is the Merida Dirt 500 used for?

The Merida Dirt 500 is used for dirt jumping, pump track riding, and trail riding. Its design and components make it ideal for tackling jumps, rollers, and rough terrains with ease.

Why choose the Merida Dirt 500?

Choose the Merida Dirt 500 for its durable alloy frame and superior suspension system. It offers reliable performance and control, making it a great choice for both beginners and experienced riders.

Who is the Merida Dirt 500 designed for?

The Merida Dirt 500 is designed for unisex riders who enjoy dirt jumping, pump track sessions, and trail adventures. Its features cater to those seeking a robust and reliable bike for off-road challenges.

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Merida Dirt 500 Dirt Jumper Bike Black we suggest the following size.

More playful More stable

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Durable and Lightweight Frame

The Merida Dirt 500 features a sturdy alloy frame that balances strength and weight, making it perfect for launching off jumps, flowing through pump tracks, and tackling rugged trails. Its crossbar design enhances stability and control during rides.

Superior Suspension System

Equipped with a Manitou Circus Expert fork, the bike offers 100mm of front travel, ensuring smooth rides over rough terrain. This air fork provides excellent shock absorption, enhancing rider comfort and control.

Reliable Braking Performance

The hydraulic disc brakes from Shimano deliver consistent and powerful stopping power. This ensures safety and confidence, whether you're navigating steep descents or performing tricks.

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

Your selected size: -

Legend

Available size

Current size

Unavailable size

Suggested sizing

Merida Dirt 500 Dirt Jumper Bike Black geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

26"

Stack

564

Reach

415

440

Top Tube Length

549

574

Seat Tube Length

300

Seat Tube Angle

76.2

Fork Length

482

Head Tube Length

110

Head Tube Angle

68.5

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

637

640

Minimum Seat Height

Maximum Seat Height
