Merida Crossway 100W Hybrid Bike Glossy Black Silver

Brand: Merida

SKU: Select a size

Size: Select a size

XS SM MD LG

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

$949.00 Full price

$949.00

Club price

$1,099.00 Full price

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Express Shipping $19.00

Select a size to view stock availability at this location.

Alloy Frame/ Suntour Fork

under 100mm Front Travel

700c Wheel Size

Hydraulic Disc Brake

Shimano Cues Groupset

Have a Question? Ask an expert on 1800 990 523

Product Details

Description

The Merida Crossway 100W Hybrid Bike is ideal for those seeking versatility and comfort across various terrains. It features a lightweight aluminum frame and a lockout Suntour NEX fork for stability and efficiency, whether commuting in the city or exploring trails. The Shimano MT200 hydraulic disc brakes provide reliable stopping power in all weather conditions. Its 9-speed Shimano CUES drivetrain ensures smooth shifting, while Maxxis Overdrive Excel tires enhance traction and control. With its thoughtful design and quality components, the Merida Crossway 100W is perfect for leisure rides and everyday journeys.

Key Features

Lightweight aluminium frame for easy handling
Lockout fork for improved riding efficiency
Reliable Shimano MT200 hydraulic disc brakes
Smooth shifting with Shimano CUES 9-speed
Maxxis Overdrive Excel tyres for versatile traction

Specifications

Product Overview

Product

Merida Crossway 100W Hybrid Bike Glossy Black Silver

Brand

Merida

Parent SKU

Merida25Crossway100WGlossyblacksilver

Size SKUs

XS: MERE2500745
SM: MERE2500746
MD: MERE2500747
LG: MERE2500748

Matrix Barcodes

XS: 4711256492094
MD: 4711256492070
LG: 4711256492063

Year Model

2025

Product Features

Frame Material

Alloy

Colour

Black

Wheel Size

700c

Brake Type

Hydraulic Disc Brake

Front Travel

under 100mm

Build

Frame

CROSSWAY TFS III; MAT aluminium; 700x50C max. WHS; 135x9 AST; BSA BBR

Fork

Suntour NEX HLO; Coil; 63 STR; Lockout; 700x48C max. WHS

Handlebars

MERIDA COMP CC; MAT aluminium; 660 WHB; 25 RHB

Grips

MERIDA EXPERT EC

Stem

MERIDA COMP TK; MAT aluminium; 31.8 DSH; adjustable

Bottom Bracket

Shimano BB-UN101; 73mm

Pedals

VP VPE-891

Saddle

MERIDA Cross Sport

Seat Clamp

MERIDA EXPERT

Wheels

Wheel Size

700c

Rims

MERIDA COMP TK; 20 IWR; 17 HRI; MAT aluminium

Hubs

F: Shimano QC300; 100x9 WHF; 32 SPH; Centerlock | R: Shimano QC300-HM; 135x9 WHR; 32 SPH; Centerlock

Tyres

Maxxis Overdrive Excel; 700x40C; wire; reflective stripe, Silkshild

Groupset

Crankset

170 mm-XXS/XS/S, 175 mm-M/XL

Chain

KMC xGlide

Brakes

Shimano MT200; 2 piston

Front Rotor

Shimano RT10; 160mm

Rear Rotor

Shimano RT10; 160mm

Shifters

Shimano CUES U4000

Front Derailleur

Shimano CUES U4000

Rear Derailleur

Shimano CUES U3020; SGS

Frequently Asked Questions

What is the Merida Crossway 100W used for?

The Merida Crossway 100W is used for versatile riding, making it suitable for commuting, recreational rides, and light off-road adventures. Its design allows for comfortable handling on both paved roads and unpaved paths.

Why choose the Merida Crossway 100W?

Choose the Merida Crossway 100W for its lightweight construction, reliable hydraulic brakes, and smooth gearing system, all of which contribute to a comfortable and efficient ride. This hybrid bike is perfect for those seeking both performance and versatility.

Who is the Merida Crossway 100W designed for?

The Merida Crossway 100W is designed for casual cyclists, commuters, and anyone looking for a reliable hybrid bike for diverse riding conditions. Its comfortable design and quality components make it suitable for riders of all skill levels.

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Merida Crossway 100W Hybrid Bike Glossy Black Silver we suggest the following size.

More comfort More speed

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Comfort and Versatility

The Merida Crossway 100W features a lightweight aluminium frame that combines comfort with agility, making it ideal for a variety of riding situations. Its geometry ensures an upright position, reducing strain on your back during longer rides.

Smooth and Reliable Stopping Power

Equipped with Shimano MT200 hydraulic disc brakes, this hybrid bike offers dependable braking performance in all weather conditions. The 160mm rotors provide excellent stopping power, ensuring safety on descents and in traffic.

Efficient Gear System

The 9-speed Shimano CUES drivetrain allows for effortless shifting, providing a wide range of gears for tackling both flat roads and hilly terrains. This system ensures that you can find the perfect gear for any situation, enhancing your overall riding experience.

Riders Height (cm)

XXS

SM/MD

MD/LG

XXL

Merida Crossway 100W Hybrid Bike Glossy Black Silver geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

700c

Stack

620

645

667

Reach

387

399

406

Top Tube Length

565

590

610

Seat Tube Length

430

510

550

Seat Tube Angle

74.0

73.5

73.0

Fork Length

468

Head Tube Length

130

155

175

Head Tube Angle

70.5

71.0

71.5

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

639

Minimum Seat Height

Maximum Seat Height
