$1850 Off Full Price

Cube Kathmandu Hybrid ONE 625 Trapeze Electric Hybrid Bike 625Wh Battery Swampgrey'n'Black

Brand: Cube

SKU: Select a size

Size: Select a size

SM MD

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

$3,649.00 Full price

$3,649.00

Club price

$5,499.00 Full price

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Express Shipping $19.00

Select a size to view stock availability at this location.

Off-Road Hills & Heavy Loads / 85 Nm Torque

Up to 73 km Range

Bosch Performance CX Gen 4 Motor

Alloy Frame/ Suntour Fork

100mm Front Travel

625Wh Battery

Have a Question? Ask an expert on 1800 990 523

Product Details

Description

The Cube Kathmandu Hybrid ONE 625 Trapeze Electric Hybrid Bike is designed for both city commuting and off-road exploration. It features a lightweight Aluminium Superlite frame and Efficient Comfort Geometry for a smooth ride. The bike is equipped with a 100mm SR Suntour NVX30 Coil fork, a Shimano Deore 10-speed drivetrain, and powerful hydraulic disc brakes, ensuring exceptional performance and comfort.

Key Features

Aluminium Superlite frame with Boost148
SR Suntour NVX30 Coil, 100mm fork
Shimano Deore 10-speed drivetrain
Fully integrated battery and internal routing
Hydraulic disc brakes for superior control

Specifications

Product Overview

Product

Cube Kathmandu Hybrid ONE 625 Trapeze Electric Hybrid Bike 625Wh Battery Swampgrey'n'Black

Brand

Cube

Parent SKU

CUEB698215

Size SKUs

SM: CUEB698215TP50
MD: CUEB698215TP54

Matrix Barcodes

SM: 4054571454393
MD: 4054571454409

Year Model

2024

Product Features

Frame Material

Alloy

Frame Style

Trapeze

Colour

Grey

Brake Type

Hydraulic Disc Brake

Gears

1 x 10

Front Travel

100mm

Motor and Battery System

Drive Type

Mid Drive

Motor Brand

Bosch

Motor

Bosch Performance CX Gen 4 25KPH

Torque (Nm)

Motor Climbing Ability

Off-Road Hills & Heavy Loads

Battery Size (Watt-Hours)

625

Battery

Bosch Powertube 625

Max. Range (KMs)

Display

Bosch Intuvia 100

Build

Frame

Aluminium Superlite, Gravity Casting Technology, Efficient Comfort Geometry, Boost148, Fully Integrated Battery, Integrated Carrier 3.0, Advanced Internal Cable Routing, 1.5 Headtube (EE: Tapered Headtube)

Fork

SR Suntour NVX30 Coil, 100mm

Handlebars

CUBE Comfort Trail Bar, 700mm

Headset

M/Z: ACROS AZF-1035, ICR (Integrated Cable Routing), BlockLock 120Â°, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm) // EE: ACROS AZX-1040, BlockLock 135Â°, Top Zero-Stack 1 1/8" (ZS 44mm), Bottom Zero-Stack 1 1/2" (ZS 56mm)

Grips

ACID Travel Comfort

Stem

CUBE Comfort Stem Pro, 31.8mm, Adjustable

Pedals

ACID PP Trekking

Saddle

Natural Fit Sequence Comfort

Seat Post

CUBE Suspension Seatpost HD, 30.9mm

Wheels

Rims

CUBE EX23, 36H, Disc

Tyres

Schwalbe Big Ben, Performance, K-Guard, 55-624

Groupset

Crankset

ACID E-Crank, 40T, 175mm (EE: 170mm)

Chain

KMC X12

Brakes

Shimano BR-MT200, Hydr. Disc Brake (180/180)

Front Rotor

180mm

Rear Rotor

180mm

Shifters

Shimano Deore SL-M4100-R, Rapidfire-Plus

Rear Derailleur

Shimano Deore RD-M4120-SGS, 10-Speed

Cassette

10 Speed

Frequently Asked Questions

What is the Cube Kathmandu Hybrid ONE 625 Trapeze used for?

The Cube Kathmandu Hybrid ONE 625 Trapeze is designed for versatile use, making it ideal for both urban commutes and off-road explorations. Its robust construction and powerful features ensure it performs well in a variety of environments.

Why choose the Cube Kathmandu Hybrid ONE 625 Trapeze?

Choosing the Cube Kathmandu Hybrid ONE 625 Trapeze means opting for a bike that combines comfort, reliability, and advanced technology. With its integrated design and high-quality components, it's a great choice for those seeking a dependable electric hybrid bike.

Who is the Cube Kathmandu Hybrid ONE 625 Trapeze designed for?

The Cube Kathmandu Hybrid ONE 625 Trapeze is designed for riders who need a versatile bike that can handle both daily commutes and weekend adventures. It's ideal for those who value comfort, performance, and the convenience of an electric assist.

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Cube Kathmandu Hybrid ONE 625 Trapeze Electric Hybrid Bike 625Wh Battery Swampgrey'n'Black we suggest the following size.

More comfort More speed

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Range

Calculate your range

E-Bike Range Estimator

Free Test Rides

Come into your local store to test ride an E-Bike today

Find a store

Shop Our E-bikes

Shop our collection of electric bikes

Shop Now

Integrated Design

The fully integrated battery and internal cable routing provide a sleek appearance while enhancing durability. This thoughtful design protects components from the elements, ensuring longevity.

Comfortable Ride

With Efficient Comfort Geometry and a suspension seatpost, the bike delivers a smooth ride even on challenging terrains. The adjustable handlebar stem allows riders to customize their riding position for maximum comfort.

Reliable Performance

Equipped with a Shimano Deore 10-speed drivetrain and hydraulic disc brakes, this bike offers consistent performance in various conditions. Whether tackling steep hills or cruising on flat roads, the Cube Kathmandu Hybrid ONE 625 Trapeze is built to excel.

Riders Height (cm)

Stack

Reach

Top Tube Length

Seat Tube Length

Seat Tube Angle

Fork Length

Head Tube Length

Head Tube Angle

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

Minimum Seat Height

Maximum Seat Height
