Discontinued

Norco Storm 4 29'' Cavalry Blue/Black

Brand: Norco

SKU: Select a size

Size: Select a size

MD LG XL

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Express Shipping $19.00

Select a size to view stock availability at this location.

Alloy Frame/ Suntour Fork

100mm Front Travel

29" Wheel Size

Hydraulic Disc Brake

Shimano Tourney Groupset

3 x 7 Speed

Have a Question? Ask an expert on 1800 990 523

Product Details

Description

The Norco Storm 4 Mountain Bike features a lightweight aluminum frame with a longer reach, slacker head tube angle, and steeper seat tube for efficient pedaling. It includes a Suntour XCE28 100mm travel suspension fork for adventure and speed, tidy internal cable routing, and 2.35" tire clearance for comfort.

Key Features

Tektro HD-M275 Hydraulic, Resin Pads
SR Suntour XCE28, 100mm Travel
WTB Starflight 2.25-inch Tyres
Shimano Altus/Tourney 21 speed drivetrain.

Specifications

Product Overview

Product

Norco Storm 4 29'' Cavalry Blue/Black

Brand

Norco

Parent SKU

21Norcostorm4cavalryblueblack29

Size SKUs

MD: NOHA2170621925
LG: NOHA2170621926
XL: NOHA2170621927

Year Model

2021

Product Features

Frame Material

Alloy

Frame Style

Crossbar

Colour

Blue

Wheel Size

29"

Brake Type

Hydraulic Disc Brake

Gears

3 x 7

Front Travel

100mm

Weight Limit

138kg (includes bike)

Build

Frame

Alloy

Fork

Suntour XCE28 100mm

Handlebars

X6 Alloy 740mm x 31.8/25mm Rise

Headset

Zero Stack Headset

Grips

Norco Grip

Stem

Norco Alloy 60mm

Bottom Bracket

Cartridge BB

Pedals

VP Nylon Flat Pedal

Saddle

Norco XC Saddle

Seat Post

Alloy 31.6mm

Wheels

Wheel Size

29"

Rims

WTB SX19 Rims

Hubs

F:Joytech D761DSE Alloy Disc QR | R: Joytech D762TSE Alloy Disc QR

Tyres

WTB Starflight 2.25"

Spokes

Stainless Steel 14g - Black

Groupset

Crankset

Pro Wheel TA-CQ60 42/34/24

Chain

KMC Z7 7spd

Brakes

Tektro HD-M275 Hydraulic 160mm

Front Rotor

Tektro 160mm

Rear Rotor

Tektro 160mm

Shifters

Shimano Altus SL-M315 7spd

Front Derailleur

Shimano Tourney FD-TY500 3spd

Rear Derailleur

Shimano Tourney RD-TY300 7spd

Cassette

7 Speed

Disclaimer

Please Note: Before using this vehicle, check the applicable local laws relating to your intended use of the vehicle on roads and road related areas. Please ride responsibly and follow your local laws. We do not recommend modifying your electric bike or electric scooter.

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Norco Storm 4 29'' Cavalry Blue/Black we suggest the following size.

More playful More stable

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Riders Height (cm)

XXS

Norco Storm 4 29'' Cavalry Blue/Black geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

29"

Stack

624

633

643

Reach

425

455

485

Top Tube Length

592

625

657

Seat Tube Length

470

510

550

Seat Tube Angle

75.0

Fork Length

Head Tube Length

105

115

125

Head Tube Angle

68.5

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

686

721

754

Minimum Seat Height

Maximum Seat Height
