$600 Off Full Price

Merida Silex 200 Gravel Bike Orange/Black

Merida Silex 200 Gravel Bike Orange/Black

Brand: Merida

SKU: Select a size

Size: Select a size

XS SM MD LG XL

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Express Shipping $19.00

Select a size to view stock availability at this location.

Alloy Frame/ Carbon Fork

700c Wheel Size

Mechanical Disc Brake

Shimano Sora Groupset

2 x 9 Speed

Have a Question? Ask an expert on 1800 990 523

Product Details

Description

The Merida Silex 200 Gravel Bike is designed for versatility and adventure. It features a lightweight aluminum frame with multiple fixing points for luggage, water bottles, fenders, and rear racks, making it ready for any journey. The Carbon CF2 fork enhances ride comfort and steering precision across various terrains. Equipped with a Shimano Sora gearset, it offers a wide 2 x 9, 11-32T gear range suitable for both fast flats and challenging climbs. Mechanical disc brakes ensure reliable stopping power in all conditions, while Maxxis Rambler tires provide excellent grip for off-road excursions. This bike is perfect for daily commutes, weekend gravel rides, bikepacking trips, and forest trails.

Specifications

Product Overview

Product

Merida Silex 200 Gravel Bike Orange/Black

Brand

Merida

Parent SKU

22MeridaSilex200Orange/Black

Size SKUs

XS: MEAD2246381
SM: MEAD2246392
MD: MEAD2246400
LG: MEAD2246411
XL: MEAD2246422

Year Model

2022

Product Features

Frame Material

Alloy

Frame Style

Crossbar

Colour

Orange

Wheel Size

700c

Brake Type

Mechanical Disc Brake

Gears

2 x 9

Fork Material

Carbon

Weight Limit

120kg (includes bike)

Build

Frame

Alloy

Fork

MERIDA SILEX CF2; Tapered; MAT carbon; 700x38C / 650Bx45C max. WHS

Handlebars

MERIDA EXPERT GR; MAT aluminium; 400mm (XS-S), 420mm (M), 440mm (L/XL)

Headset

MERIDA M2331 Neck

Stem

MERIDA COMP CC; MAT aluminium; 31.8 DSH; -6 ASD

Bottom Bracket

FSA PF86 MegaExo

Saddle

MERIDA COMP SL; V-mount

Seat Post

MERIDA COMP CC; MAT aluminium; 30.9 DSP; 0 SSB

Wheels

Wheel Size

700c

Rims

MERIDA COMP SL; 17 IWR; 22 HRI; MAT aluminium

Hubs

VP 173SB / VP 273SB, 100x12mm width front hub, 32 spoke holes, 6 bolt, 142x12mm width rear hub, 32 spoke holes, 6 bolt

Tyres

Maxxis Rambler; 700x38C; fold; TR; EXO

Spokes

Black stainless

Groupset

Crankset

FSA Omega; 48-32 ATC

Chain

KMC M99

Brakes

Promax DSK-330R; Mechanical disc

Front Rotor

Promax 160G 160mm

Rear Rotor

Promax 160G 160mm

Shifters

Shimano Sora

Front Derailleur

Shimano Sora

Rear Derailleur

Shimano Sora; GS

Cassette

9 Speed

Disclaimer

Please Note: Before using this vehicle, check the applicable local laws relating to your intended use of the vehicle on roads and road related areas. Please ride responsibly and follow your local laws. We do not recommend modifying your electric bike or electric scooter.

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Merida Silex 200 Gravel Bike Orange/Black we suggest the following size.

More relaxed More aggressive

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Hydroformed Tubes

Using their Hydro Forming System, Merida creates tubes that are strong yet lightweight. The tubes are inserted into a negative mould and a hot emulsion of water and oil is passed through them at pressure which enables them to be formed into complex shapes while still retaining strength.

Prolite 66 Triple Butted Aluminium

Using high-end 6066 aluminium and triple butted wall thicknesses, this frame offers strength and durability without excess weight. The hydroforming technology helps to tune the aluminium tubes to give the best possible stiffness to weight ratio.

X-Taper Headtube

The X-Tapered headtube on this bike provides room for a tapered fork to be fitted. Tapered forks provide superb stiffness and precise confidence-inspiring shifting, with this setup you'll be able to navigate streets and corners with ease!

Riders Height (cm)

Wheel Size

700c

Stack

Reach

Top Tube Length

Seat Tube Length

Seat Tube Angle

Fork Length

Head Tube Length

Head Tube Angle

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

Minimum Seat Height

Maximum Seat Height
