Merida Reacto Limited Road Bike Gunmetal Grey/Blue (2022)

Brand: Merida

SKU: Select a size

Size: Select a size

XS SM MD LG XL

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Express delivery — fastest option $19.00

Select a size to view stock availability at this location.

Carbon Frame/ Carbon Fork

700c Wheel Size

Hydraulic Disc Brake

Shimano 105 Groupset

2 x 11 Speed

Have a Question? Ask an expert on 1800 990 523

Product Details

Description

The Merida Reacto Limited aero road bike enhances its aerodynamic capabilities with the new SL45 Carbon wheelset. Designed for performance, it offers stable ride characteristics, allowing for a comfortable experience despite its focus on speed. The CF3 Carbon aero frame and fork provide stiffness and stability, while also dampening vibrations, making it ideal for rides on cobblestones or uneven country roads.

Specifications

Product Overview

Product

Merida Reacto Limited Road Bike Gunmetal Grey/Blue (2022)

Brand

Merida

Parent SKU

22MeridaReactoLimitedGunmetalGrey/Blue

Size SKUs

XXS: MERA2263841
XS: MERA2263852
SM: MERA2263863
MD: MERA2263874
LG: MERA2263885
XL: MERA2263896

Year Model

2022

Product Features

Frame Material

Carbon

Colour

Grey

Wheel Size

700c

Brake Type

Hydraulic Disc Brake

Gears

2 x 11

Fork Material

Carbon

Weight Limit

120kg (includes bike)

Build

Frame

REACTO CF3 IV; MAT carbon; 700x30C max. WHS; 100x12/ 142x12 AST; BB86,5 BBR

Fork

REACTO CF3 IV DISC; MAT carbon; 700x30C max. WHS

Handlebars

MERIDA EXPERT CW; MAT aluminium; 380mm (XXS); 400mm (XS-S); 420mm (M), 440 (L-XL)

Headset

FSA ACR

Stem

FSA SMR ACR; MAT aluminium; -6 ASD

Bottom Bracket

SM-BB71-41B, Pressfit 86.5

Saddle

MERIDA EXPERT SL; V-mount; incl. MERIDA minitool

Seat Post

MERIDA Team CW; Aero shape; 15 SSB; Carbon

Wheels

Wheel Size

700c

Rims

MERIDA TEAM SL45; 100x12 WHF; 142x12 WHR; 19 IWR; 45 HRI; Centerlock; MAT Carbon

Tyres

Continental Ultra Sport III; 700x25C; fold

Groupset

Crankset

Shimano 105; 52-36 ATC

Chain

KMC X11

Brakes

Shimano 105; Hydraulic disc

Shifters

Shimano 105 disc

Front Derailleur

Shimano 105

Rear Derailleur

Shimano 105; GS

Cassette

11 Speed

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Merida Reacto Limited Road Bike Gunmetal Grey/Blue (2022) we suggest the following size.

More relaxed More aggressive

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Shimano 105 Groupset

Reliable and efficient, the Shimano 105 groupset is a tried and tested groupset proven time and again. Known for its reliability at an affordable price, the 105 is the perfect groupset for those wanting to ride with confidence.

Lightweight CF3 Frame

The lightweight CF3 carbon aero frame only weighs approx. 1,150 g (size M) and utilises Nano Matrix technology. The Carbon fibers are bonded together using an epoxy resin with added nano particles which increases the impact resistance by up to 40%!

Merida SL45 Wheelset

The Merida Team carbon SL45 wheelset is Merida's lightweight, aero rims designed to slice through the air, reducing drag and keeping you rolling faster.

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

Your selected size: -

Legend

Available size

Current size

Unavailable size

Suggested sizing

Merida Reacto Limited Road Bike Gunmetal Grey/Blue (2022) geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

700c

Stack

Reach

Top Tube Length

Seat Tube Length

Seat Tube Angle

Fork Length

Head Tube Length

Head Tube Angle

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

Minimum Seat Height

Maximum Seat Height
