Merida eSpresso 400 EQ Electric Hybrid Bike Dark Silver/Black

Brand: Merida

SKU: Select a size

Size: Select a size

XS SM MD LG XL

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

$2,999.00 Full price

$2,999.00

Club price

$4,499.00 Full price

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Express Shipping $19.00

Select a size to view stock availability at this location.

Off-Road Hills & Heavy Loads / 85 Nm Torque

Up to 59 km Range

Shimano STePS EP6 Motor

Alloy Frame/ Suntour Fork

under 100mm Front Travel

504Wh Battery

Have a Question? Ask an expert on 1800 990 523

Product Details

Description

The Merida eSpresso 400 EQ is a versatile electric hybrid bike designed for both urban commuting and off-road adventures. It features a lightweight eSpresso Lite IV aluminum frame and powerful Shimano components, ensuring a smooth and efficient ride. This makes it ideal for navigating city streets or exploring new trails.

Key Features

Shimano EP6 motor with 85Nm torque
Suntour NEX E25 coil fork, 63mm travel
Shimano CUES U4000 1x9 drivetrain
Shimano RT10 hydraulic disc brakes

Specifications

Product Overview

Product

Merida eSpresso 400 EQ Electric Hybrid Bike Dark Silver/Black

Brand

Merida

Parent SKU

Merida25eSPRESSO400EQMattDarkSilverBlack

Size SKUs

SM: MEEB2502552
MD: MEEB2502553
LG: MEEB2502554
XL: MEEB2502555

Matrix Barcodes

SM: 25025522552
MD: 25025532553
LG: 25025542554
XL: 25025552555

Year Model

2025

Product Features

Frame Material

Alloy

Frame Style

Crossbar

Colour

Silver

Wheel Size

700c

Brake Type

Hydraulic Disc Brake

Gears

1 x 9

Front Travel

under 100mm

Motor and Battery System

Drive Type

Mid Drive

Motor Brand

Shimano

Motor

Shimano EP6, 25KPH

Torque (Nm)

Motor Climbing Ability

Off-Road Hills & Heavy Loads

Battery Size (Watt-Hours)

504

Battery

Shimano EN805-L 504 Wh

Max. Range (KMs)

Display

Shimano SC-EN500

Build

Frame

eSPRESSO LITE IV MAT aluminium 700x50C with fender max WHS 142x12 AST intube

Fork

Suntour NEX E25; Coil; 63 STR; 700x52C max WHS

Handlebars

MERIDA EXPERT; MAT aluminium; 660 WHB; 15 RHB

Grips

MERIDA EXPERT TK

Stem

MERIDA EXPERT CT; MAT aluminium; 31.8 DSH; adjustable

Pedals

VP VPE-891

Saddle

MERIDA EXPERT TK II; V-mount

Seat Post

MERIDA EXPERT CC; MAT aluminium; 34.9 DSP; 0 SSB

Seat Clamp

MERIDA EXPERT

Wheels

Wheel Size

700c

Rims

MERIDA COMP TK; 20 IWR; MAT aluminium

Tyres

F: ETB00449900 M2028eP | R:

Groupset

Crankset

MERIDA EXPERT TK; 165mm

Chain

Shimano LG500

Brakes

Shimano MT-200; 2 piston

Front Rotor

Shimano RT10; 180 mm

Rear Rotor

Shimano RT10; 180 mm

Rear Derailleur

Shimano CUES U4000

Cassette

9 Speed

Frequently Asked Questions

What is the Merida eSpresso 400 EQ used for?

The Merida eSpresso 400 EQ is designed for urban commuting and versatile riding, capable of handling city streets and occasional off-road trails with ease.

Why choose the Merida eSpresso 400 EQ?

This bike stands out due to its lightweight eSpresso Lite IV aluminium frame, advanced Shimano EP8 motor, and integrated 660Wh battery, offering a powerful and efficient ride experience suitable for various terrains.

Who is the Merida eSpresso 400 EQ designed for?

Designed for urban commuters and riders seeking an electric bike with robust performance, comfort, and the ability to handle both city streets and light off-road trails effortlessly.

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Merida eSpresso 400 EQ Electric Hybrid Bike Dark Silver/Black we suggest the following size.

More comfort More speed

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Range

Calculate your range

E-Bike Range Estimator

Free Test Rides

Come into your local store to test ride an E-Bike today

Find a store

Shop Our E-bikes

Shop our collection of electric bikes

Shop Now

Powerful Motor

The Shimano EP6 motor provides 85Nm of torque, ensuring powerful assistance for various riding conditions. This feature enhances your riding experience, making climbs and long distances more manageable.

Reliable Braking System

Equipped with Shimano RT10 hydraulic disc brakes and 180mm rotors, the Merida eSpresso 400 EQ offers dependable stopping power in all weather conditions. This ensures safety and control, whether you're commuting or adventuring off-road.

Extended Range Battery

The integrated 660Wh Shimano battery provides extended range capability, ideal for longer rides and commutes. This means you can enjoy your journey without worrying about running out of power.

Riders Height (cm)

Wheel Size

700c

Stack

649

663

684

712

Reach

410

416

424

436

Top Tube Length

590

600

620

640

Seat Tube Length

470

510

550

590

Seat Tube Angle

74.5

74.0

Fork Length

489

Head Tube Length

140

155

175

205

Head Tube Angle

69.5

70.0

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

768

802

836

873

Minimum Seat Height

Maximum Seat Height
