$1502 Off Full Price

Cube Stereo ONE77 Pro 29inch Dual Suspension Mountain Bike Black Anodized

Brand: Cube

SKU: Select a size

Size: Select a size

MD LG XL XXL

Not sure what sized bike is best?

Answer a few short questions and we'll make a recommendation on which size is best for you.

$4,497.00 Full price

$4,497.00

Club price

$5,999.00 Full price

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Express Shipping $19.00

Select a size to view stock availability at this location.

Alloy Frame/ Fox Fork

170mm Front Travel / 170mm Rear

29" Wheel Size

SRAM GX Eagle Groupset

1 x 12 Speed

Tubeless Compatible

Have a Question? Ask an expert on 1800 990 523

Product Details

Description

The Stereo ONE77's frame utilizes Cube's four-bar suspension design and Agile Trail Geometry, ensuring excellent suspension performance and reliable handling across various trail conditions. It features a flip chip and dual mounting points for both air and coil shocks, allowing for a progressive rear suspension setup. An angle adjustment insert lets you customize the geometry to your liking. The frame accommodates both air and coil shocks, with covered bearings, internally routed cables, and a threaded bottom bracket, minimizing maintenance time. This bike redefines the capabilities of big-travel, big-wheeled bikes.

Key Features

Proven four-bar suspension design for superb performance
Agile Trail Geometry for adventurous line choices
Adjustable headset angle for customized handling
High-performance aluminium for strength and durability
170mm travel for conquering diverse trails

Specifications

Product Overview

Product

Cube Stereo ONE77 Pro 29inch Dual Suspension Mountain Bike Black Anodized

Brand

Cube

Parent SKU

CURE23656100

Size SKUs

LG: CUDS236100000L
MD: CUDS236100000M
XL: CUDS23610000XL
XXL: CUDS2361000XXL

Matrix Barcodes

LG: 4.05457E+12
MD: 4.05457E+12
XL: 4.05457E+12
XXL: 4.05457E+12

Year Model

2023

Product Features

Frame Material

Alloy

Colour

Black

Wheel Size

29"

Gears

1 x 12

Front Travel

170mm

Rear Travel

170mm

Weight

15.9 kg

Features

Tubeless Ready

Weight Limit

115 kg

Build

Frame

HPA Advanced Hydroform, ATG, ETC 4-Link, Air/Coil Shock Mount Flip-Chip, ISCG Mount, AXH

Fork

Fox 38 Float Performance GRIP, 3-Position w/ Micro Adjust, Tapered, 15x110mm, 170mm

Shock

Fox Float X2, 230x65mm, Low Speed Rebound & Compression w/ 2-Position Lever

Handlebars

Race Face Chester 35, 780mm

Headset

ACROS Integrated, Top 1 1/8", Bottom 1 1/2", Fiber Inserts for 0.6° Angle Adjustment

Grips

ACID Disrupt, Soft Compound

Stem

Race Face Aeffect R 35

Saddle

Natural Fit Venec Lite

Seat Post

CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm

Seat Clamp

CUBE Screwlock, 34.9mm

Wheels

Wheel Size

29"

Rims

Newmen Evolution SL A.30, 15x110mm/12x148mm, Tubeless Ready

Tyres

F: Maxxis Assegai, MaxxGrip/EXO+, Tubeless Ready, 2.5 WT | R: Maxxis Minion DHR II, MaxxTerra/EXO+, Tubeless Ready, 2.4 WT

Spokes

28/28 Spokes

Groupset

Crankset

Sram GX Eagle™ Boost DUB, 30T

Chain

Sram SX Eagle™

Brakes

Magura MT5, Hydr. Disc Brake (203/180)

Front Rotor

203mm

Rear Rotor

180mm

Shifters

Sram NX Eagle™ Trigger

Rear Derailleur

Sram GX Eagle™, 12-Speed

Cassette

12 Speed

Frequently Asked Questions

What is the Cube Stereo ONE77 Pro 29inch used for?

The Cube Stereo ONE77 Pro 29inch is used for mountain biking, specifically designed to handle rugged trails and challenging terrains with ease.

Why choose the Cube Stereo ONE77 Pro 29inch?

Choose the Cube Stereo ONE77 Pro 29inch for its advanced dual suspension system, lightweight yet durable frame, and reliable hydraulic disc brakes, making it ideal for adventurous mountain biking.

Who is the Cube Stereo ONE77 Pro 29inch designed for?

The Cube Stereo ONE77 Pro 29inch is designed for mountain biking enthusiasts who seek a versatile and high-performance bike capable of tackling various terrains.

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Cube Stereo ONE77 Pro 29inch Dual Suspension Mountain Bike Black Anodized we suggest the following size.

More playful More stable

XXL

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

High Performance Aluminium

High-performance aluminium is all about extracting the best possible performance from this strong, durable material. Cube select precisely the right grade of alloy for your needs, carefully tweak tube profiles to suit each application, and then meticulously weld each frame. It's your guarantee of a light, strong, durable and safe bike.

Agile Trail Geometry

Agile Trail Geometry is a development of Cube's popular and well-received Agile Ride Geometry, with a focus on riders who enjoy pushing their limits on the trails. By lowering standover height and allowing more room for the rider to move around over the bike, Cube have created a setup that rewards adventurous line choices. Because, after all, it's all about having fun.

Adjustable Headset Angle

When you're harnessing gravity, the trail is challenging and every second counts, the geometry of your CUBE is a critical component. That's why our adjustable headset allows you to tweak your head angle, so you can set your bike up just the way you like it. A little slacker for more stability, or a little steeper for better agility. The choice is yours...

Riders Height (cm)

Cube Stereo ONE77 Pro 29inch Dual Suspension Mountain Bike Black Anodized geometry diagram

Legend

ST Seat Tube
STA Seat Tube Angle
R Reach
TT Top Tube
BD Bottom Bracket Drop
S Stack
CS Chain Stay Length
HT Head Tube
WB Wheel Base
HTA Head Tube Angle
FL Fork Length

Wheel Size

29"

Stack

627

629

638

656

Reach

444

464

484

504

Top Tube Length

585

605

629

655

Seat Tube Length

420

470

Seat Tube Angle

76.5

Fork Length

Head Tube Length

103

105

115

135

Head Tube Angle

64.4

Handlebar Height

Bottom Bracket Drop

Chainstay Length

Wheelbase

Standover Height

Minimum Seat Height

Maximum Seat Height
