Cube Touring Hybrid ONE 500 Trapeze Electric Hybrid Bike Grey/Black

Brand: Cube

SKU: CUEB214310TP50

Size: SM

REQUEST A PRICE BEAT

Pick up Delivery

Your store:

No location set

No click & collect information available for this location.

Click & Collect:

In Store

Select a size to view stock availability at this store.

$9.90 Not available

Express Shipping $19.00

Select a size to view stock availability at this location.

Moderately Steep Hills / 50 Nm Torque

Up to 81 km Range

Bosch Active Plus Gen 3 Motor

Alloy Frame/ Suntour Fork

100mm Front Travel

500Wh Battery

Have a Question? Ask an expert on 1800 990 523

Product Details

Description

The Cube Touring Hybrid ONE 500 Trapeze Electric Hybrid Bike is the perfect blend of comfort and practicality, making it an excellent choice for both commuting and touring. With its robust Bosch e-bike components, sleek trapeze frame, and a powerful 500Wh battery, this bike ensures a smooth ride across various terrains, enhanced by a 9-speed Shimano drivetrain and reliable suspension.

Key Features

Aluminium Superlite Trapeze Frame
SR Suntour XCM ATB Coil Fork
Shimano BR-MT200 Hydraulic Disc Brakes
Bosch PowerTube 500 Battery
50km Estimated Battery Range

Specifications

Product Overview

Product

Cube Touring Hybrid ONE 500 Trapeze Electric Hybrid Bike Grey/Black

Brand

Cube

Parent SKU

21CubeTouringHybridONE500Trapezegreynblack

Size SKUs

XS: CUEB214310TP46
SM: CUEB214310TP50
MD: CUEB214310TP54

Year Model

2021

Product Features

Frame Material

Alloy

Frame Style

Trapeze

Wheel Size

700c

Brake Type

Hydraulic Disc Brake

Gears

1 x 9

Front Travel

100mm

Weight

24.9kg

Charge Time

Weight Limit

135kg (includes bike)

Motor and Battery System

Drive Type

Mid Drive

Motor Brand

Bosch

Motor

Bosch Drive Unit Active Plus Generation 3 (50Nm) Cruise (250Watt) 25KPH

Torque (Nm)

Motor Climbing Ability

Moderately Steep Hills

Battery Size (Watt-Hours)

500

Battery

Bosch PowerTube 500

Max. Range (KMs)

Charge Time (Hours)

Display

Bosch Purion

Build

Frame

Aluminium Superlite, Gravity Casting Technology, Efficient Comfort Geometry, Tapered Headtube, Full Integrated Battery, Semi-Integrated Carrier

Fork

SR Suntour XCM ATB Coil, 100mm

Handlebars

CUBE Comfort Trail Bar, 700mm

Headset

M, L: ACROS AZF-1039, 1 1/8" straight, Top Zero-Stack 1 1/8" (ZS 44mm), Bottom Zero-Stack 1 1/2" (ZS 56mm) // EE: ACROS AZX-1041, BlockLock 135 deg, 1 1/8" straight, Top Zero-Stack 1 1/8" (ZS 44mm), Bottom Zero-Stack 1 1/2" (ZS 56mm)

Grips

CUBE Performance Grip

Stem

CUBE Performance Stem Pro, 31.8mm

Pedals

ACID PP Trekking

Saddle

Natural Fit Sequence Comfort

Seat Post

CUBE Performance Post, 30.9mm

Wheels

Wheel Size

700c

Rims

CUBE EX23, 36H, Disc, Tubeless Ready

Hubs

Shimano HB-TX505, QR, Centerlock

Tyres

Schwalbe Range Cruiser, Active, 47-622

Groupset

Crankset

ACID E-Crank, 38T (175mm // EE: 170mm)

Chain

KMC X9

Brakes

Shimano BR-MT200, Hydr. Disc Brake (180/180)

Shifters

Shimano SL-M3100-R, Rapidfire-Plus

Front Derailleur

Included in Motor

Rear Derailleur

Shimano RD-M3100-SGS, 9-Speed

Cassette

9 Speed

Frequently Asked Questions

What is the Cube Touring Hybrid ONE 500 Trapeze used for?

The Cube Touring Hybrid ONE 500 Trapeze is designed for both commuting and touring, providing a comfortable and efficient ride. Its versatile features make it suitable for various terrains and distances.

Why choose the Cube Touring Hybrid ONE 500 Trapeze?

Choose the Cube Touring Hybrid ONE 500 Trapeze for its powerful Bosch e-bike system and practical design. It offers a balanced ride, excellent off-road capability, and essential commuting features.

Who is the Cube Touring Hybrid ONE 500 Trapeze designed for?

The Cube Touring Hybrid ONE 500 Trapeze is designed for cyclists seeking a reliable and comfortable hybrid bike. It caters to commuters and touring enthusiasts who value performance and versatility.

Disclaimer

Please Note: Before using this vehicle, check the applicable local laws relating to your intended use of the vehicle on roads and road related areas. Please ride responsibly and follow your local laws. We do not recommend modifying your electric bike or electric scooter.

Find Your Size

Step 1: Measure your height

Take off your shoes
Stand with your back straight against a wall
Balance a book on your head to mark your height on the wall
Measure your height by the distance from the floor to the mark

Your height:

Find Your Size

Step 2: Adjust your inseam

Based on your height, we’ve calculated a starting point.
You can measure your inseam by tucking a book between your legs so there is pressure but it isn’t uncomfortable.
Inseam typically falls with 5cm of the average.

Your inseam:

Find Your Size

Your results

For the Cube Touring Hybrid ONE 500 Trapeze Electric Hybrid Bike Grey/Black we suggest the following size.

More comfort More speed

Height: --

Inseam: --

Adjusted Height: --

Find Your Size

We have saved your measurements.

Recommended sizes will now be highlighted on the page.

PERFECT RIDE GUARANTEE

If you don't love it, you can swap it, up to 30 days from purchase!* Learn more »

FREE BIKE BUILD

We'll build your bike for free when you click and collect at any 99 Bikes store.

FIRST FREE TUNE-UP

Every bike comes with a complimentary free tune-up and safety check. Learn more »

Range

Calculate your range

E-Bike Range Estimator

Free Test Rides

Come into your local store to test ride an E-Bike today

Find a store

Shop Our E-bikes

Shop our collection of electric bikes

Shop Now

Powerful Bosch E-Bike System

The Cube Touring Hybrid ONE 500 Trapeze features a Bosch Active Plus Generation 3 drive unit, providing 250 watts of power. This system allows riders to cover greater distances with less effort, enhancing the overall riding experience.

Versatile Off-Road Capability

Equipped with a Suntour XCM ATM Coil Suspension Fork offering 100mm of travel, this bike is ready for off-road adventures. It maintains control and comfort whether navigating trails or city streets.

Comprehensive Commuting Features

This hybrid bike includes full-length mudguards, integrated lights, a kickstand, and a rear rack. These practical features make the Cube Touring Hybrid ONE 500 Trapeze an excellent choice for daily commuting and touring needs.
